Hikvision 305 m CAT5E UTP Network Cable (Solid Copper, 0.5 mm, CM)

DS-1LN6-UU bd

• General
• Core Color1 White- Blue /Blue 2 White-Orange /Orange 3 White-Green /Green 4 White- Brown /Brown
• PackingWooden Tray & Carton
• Carton DimensionPer request
• Packing Length305±1.5m
• Rip-CordYes
• Drain WireNo
• Sheath Physical PropertiesBefore Aging Tensile Strength (Mpa) ≥13.5 Elongation(%) ≥150 Aging Period (℃×hrs) 100℃×24h×10d After Aging Tensile Strength(Mpa) ≥12.5 Elongation(%) ≥125 Cold bend(-20±2℃×4h) 8×Cable O.D.，No visible cracks
• Electrical Characteristics (20℃)1.0-250.0MHz Impedance ((Ω) 100±15 1.0-250.0MHz Delay Skew (ns/100m) ≤45 DC Resistance (Ω/100m) max 9.38 DC Conductor Resistance Unbalance (%) max 5.0

• Conductor
• MaterialSolid-Bare Copper Content 99.95%
• Nom.O.D.(Mm)0.565±0.005

• Insulation
• MaterialHDPE
• Diameter1.02±0.05mm

• Sheath
• Thickness0.55±0.05 mm
• External O.D.6.2±0.4 mm
• SurfaceClean,Frap,Satiation
• MaterialPVC(complies RoHS),CM
• ColorOrange RAL2003

• Surface Printing
• Letter Height3.0±0.3mm
• ColorBlack
• Print Error & Space≤±0.5%，1m
