ZKTeco SC02-I365A – All-in-One Interactive Panel for Professional Environments

The ZKTeco SC02-I365A 65-inch Interactive Display is an advanced smart solution designed to revolutionize communication in professional and educational spaces. With its stunning 4K UHD resolution and multi-touch capability, this all-in-one panel allows for seamless interaction, high-precision annotation, and smooth digital collaboration.

Ideal for business meetings, classrooms, financial institutions, and healthcare settings, the SC02-I365A features wireless screen sharing, split-screen functionality, and intuitive whiteboarding tools. It supports both Android and Windows dual systems, making it highly versatile for a wide range of applications—from remote learning to corporate strategy sessions.

The durable build and sleek design make it suitable for wall mounting or conference room integration. Users can easily present, brainstorm, teach, or train without the need for additional peripherals. Whether you're hosting hybrid meetings or conducting digital lessons, this device brings clarity, control, and creativity to every interaction.

With smart features and reliable performance, the ZKTeco SC02-I365A is a future-ready display for organizations seeking to enhance productivity and inspire knowledge sharing.

Key Specifications of ZKTeco SC02-I365A:

Display

• Screen Sizes: 65″ (SC02‑I365A), 75″ (SC02‑I375A), 86″ (SC02‑I386A)

• Panel Type: ADS (65″ & 75″); IPS (86″)

• Backlight: D‑LED, 50,000 hours life (typ.)

• Resolution: 3840×2160 pixels (4K UHD)

• Brightness: 450 cd/m² (typ.)

• Contrast Ratio: 1200 : 1 (typ.)

• Response Time: 8 ms (typ.)

• Refresh Rate: 60 Hz

• Aspect Ratio: 16:9

• Viewing Angle: 178° horizontal / 178° vertical

• Color Support: 1.07 billion (8‑bit + FRC)

• Bonding Technology: Zero-gap bonding between tempered glass and display

Touch Interface

• Touch Tech: Advanced infrared

• Touch Points: Up to 50 simultaneous touches

• Touch Response: ≤ 3 ms (single and multi‑touch)

• Accuracy: ±1 mm within central 90%

• Surface Coating: High transparent, smooth, anti‑glare

• Glass Surface Hardness: Pencil 9H / Mohs 7

• Writing Height: ≤ 1 mm

System & Performance

• Processor (CPU): Quad‑core A73 + Quad‑core A53

• Graphics (GPU): Mali‑G52 MP8

• Memory/Storage: 8 GB RAM, 128 GB ROM

• Operating System: Android 14; optional Windows 11

Connectivity

• Front Ports: USB 3.0 × 2; Type‑C (65W) × 1

• Side Ports: Touch‑USB × 2; DisplayPort × 1; HDMI IN (ARC) × 1; HDMI IN (CEC) × 1; Type‑C × 1; USB2.0 × 1; USB3.0 × 2; OPS slot × 1

• Bottom Ports: Audio‑IN × 1; VGA × 1; LAN IN/OUT × 2; RS‑232 × 1; MIC IN × 1; HDMI OUT × 1; Audio‑OUT × 1; SPDIF × 2

• Wireless Connectivity: Wi‑Fi 6 (IEEE 802.11 ax/ac/b/g/n supporting both 2.4 GHz and 5 GHz), Bluetooth 5.0 (also backwards compatible), NFC (ISO/IEC 14443 A/B)

Built‑In Peripherals

• Camera: 48 MP (diagonal FOV ~114.9°), with face tracking & sound‑localization

• Microphone: 8‑mic array, 3D noise reduction, AEC & AGC support

• Speakers: Dual 20 W + optional 20 W subwoofer
