MG10 10 Channel Audio Mixer

Brands: DSPPA

Model : MG10

Status : In Stock

Key Features :

● Up to 4 microphones / 10 line inputs (4 mono + 3 stereo)
● 1 stereo bus
● 1AUX (including FX)
● "D-PRE" speaker, with a reverse transistor circuit
● Single knob compressor
● Advanced effects: SPX, with 24 sets of preset effects
● 24-bit / 192kHz 2 in / out USB audio function
● Connect to iPad (2 or higher) via Apple iPad Camera Connection Kit / Lightning to USB Camera Adapter (connection adapter)
● Cubase Al DAW download software
● PAD switch on mono input channel
● + 48V phantom power supply
● XLR balanced output
● Metal body

Sale Price :

৳ 0

- +

01700514444 01407555777

01407555777 01700514444

প্রযুক্তি পণ্যের অস্থিতিশীল বাজার পরিস্থিতির কারণে যে কোন সময় মূল্য পরিবর্তন হতে পারে। হেল্পলাইন নাম্বারে কল দিয়ে পণ্যের স্টক ও ডেলিভারি সম্পর্কে জেনে নেওয়ার অনুরোধ রইল

Video
Specification
Description
FAQ
Reviews (0)

Product Video

Specification

MG10XU/MG10
Frequency response	Enter to STEREO OUT	+ 0.5dB / -1.0dB (20Hz to 48kHz), reference rated output level @ 1kHz, GAIN knob: minimum
Total harmonic distortion（THD+N）	Enter to STEREO OUT	0.02% @ + 14dBu (20Hz to 20kHz), GAIN knob: minimum 0.003% @ + 24dBu (1kHz), GAIN knob: minimum
Hum and noise*1 (20Hz to 20kHz)	Same input noise	-128dBu (Mono input channel, Rs: 150Ω, GAIN knob: max)
Hum and noise*1 (20Hz to 20kHz)	Residual output noise	-102dBu(STEREO OUT, STEREO LEVEL Knob: Min）
Crosstalk（1kHz) *2		-83dB
Input channel		10 channels; mono [MIC / LINE]: 4, stereo[LINE]:3
Output channel		STEREO OUT:2,PHONES:1，MONITOR OUT:1, AUX[FX] SEND:1
Bus-bar		stereo:1，AUX[FX]，1
Input channel function	PAD (Mono)	26dB
	HPF (Mono)	80Hz,12dB / octave
	COMP	Single knob compressor Threshold: + 22dBu to -8dBu, ratio: 1: 1 to 4: 1, output level: 0dB to 7dB, attack time: about 25 milliseconds, Release time: about 300 milliseconds
	EQ HIGH	Gain: + 15dB / -15dB, frequency: 10kHz slope
	EQ MID	Gain: + 15dB / -15dB, frequency: 2.5kHz peak
	EQ LOW	Gain: + 15dB / -15dB, frequency: 100Hz slope
	PEAK LED (Mono)	When the EQ signal reaches the distortion below 3dB when the LED is turned on
Meter level	Post STEREO LEVEL Knob	2x7-dot pitch LED level meter [PEAK, +10, +6, 0, -6, -10, -20dB]
Built-in digital effects	SPX algorithm	24 programming（MG10XU)
USB Audio（MG10XU）	2 IN/2 OUT	USB Audio 2.0 compatible, sampling rate: maximum 192kHz, Bit depth:24-bit (MG10XU)
Phantom power supply voltage		+48V
Power Adapter		PA-10 (AC38 VCT, 0.62A, cable length = 3.6m) or the same grade recommended by DSPPA
Power consumption		22.9W
physical dimension（W× H × D）		244mm×71mm×294mm (9.6”×2.8”×11.6”）
Net weight		MG10XU:2.1kg (4.63 lbs.), MG10：1.9kg (4.19 lbs.)
Include attachments		AC adapter, instruction manual, Cubase AI download information (MG10XU), technical specifications
Optional accessories		Bracket Adapter: BMS-10A, Pedal Switch: FC5 (MG10XU)
Operating temperature		0 to +40℃

Description

MG10 10 Channel Audio Mixer

Name: MG10 10 Channel Audio Mixer
Brand: DSPPA
Availability: InStock

MG series has intuitive, easy to use interface, including from 6 channels to 20 channels in a variety of models, suitable for a variety of users and usages. The firm structure and flexible design make the series create the highest performance, best sound quality and stability in applications such as installation, recording and live performance.
The newly released MG series of rich mixer product lines are suitable for a variety of mixing environments. This powerful product line includes a variety of channel configuration models and models with SPX effects and USB audio interface, which can be mobile or fixed for various applications such as live sound and recording, so as to meet the requirements from the monitor to meetings, live performances such as sound reinforcement and other needs of the application environment.
